Client:  JPL Space Exploration

This is a high voltage stepper power supply designed to as part of a space exploration instrument.

HV Stepper Power Supply

]]> F16 Avionics Power Supply https://astrospace.com/project/f16-aka-falcon/ Wed, 22 Sep 2021 21:12:51 +0000 https://astrospace.com/?post_type=dt_portfolio&p=4631
F16

Client: DOD Contractor

The F16 first flew in 1974 and is used by many nations around the world. It required a higher capacity Power Supply Assembly (PSA) that could support increased loads while occupying the same volume package.

]]> NASA Exploration https://astrospace.com/project/mars-01/ Mon, 02 Dec 2019 12:27:22 +0000 https://the7.io/company/?post_type=dt_portfolio&p=2784

Hubble Space Telescope

Client:  GSFC

Reviewed failures of various onboard instruments prior to Service Mission 4:

  • Assess root cause of 9 anomalies
  • Used modeling techniques to simulate and assess possible failure modes
  • Evaluate vendors products for possible overstresses
  • Presented a detailed report to SM4 Program Management at GSFC
]]> SSPA EPC Power Supply https://astrospace.com/project/sspa/ Fri, 08 Nov 2019 09:37:25 +0000 https://the7.io/company/?post_type=dt_portfolio&p=1928

Military & Commercial Space Payload Applications

SSPA EPC Commercial Flight Unit

Military Communications SSPA EPC – Flight

Client:  DOD & Commercial

State-of-the-Art high-efficiency performance to reduce spacecraft power consumption.  Total-Dose, SEU, and Prompt-Dose Radiation Hardened designs.  Compact design to minimize volume and weight.  High MTBF.

WCA Example
]]> JPL Space Missions https://astrospace.com/project/mars-observer/ Fri, 08 Nov 2019 04:46:03 +0000 https://the7.io/company/?post_type=dt_portfolio&p=1936

Client: JPL

Hot Redundant Multi-Output High-Efficiency DC/DC Converter.  Extensive protection and cross-strapping features to provide fault tolerance.  Total-Dose and SEU Radiation Hardened design.

Fact Sheet
]]> Medical Equipment https://astrospace.com/project/dpc-medical-equipment/ Fri, 08 Nov 2019 04:34:28 +0000 https://the7.io/company/?post_type=dt_portfolio&p=1912

Client:  Medical Equipment

This device required a load cell to monitor water level supply in holding tank in to insure proper operation and accuracy of the blood analyzer. Finite Element Analysis of the design and fabrication of the prototype completed this project.

Mass Sensor for Liquid Level Detection

]]>
